EXCITE/EXCITE+ LINE - ASSEMBLY KIT VISIO/VISIOWEB-UNITY3.0
Installation Manual UNITY 3.0- Rev. 1.0
e-mail: support@technogym.com
Pag. 27
3. Remove the 4 black self-threading screws
(N), at the right side of the upper dashboard
guard, using a medium Phillips screwdriver.
4. Loosen the 3 screws (O), at the right side of
the lower dashboard guard, using a 4mm hexa-
gonal wrench.
If the opening of the lateral right guard doesn’t
allow to cut the cable tie, that blocks the High
Kit - Low Kit connection cable, remove the th-
ree screws (O).
