EXCITE/EXCITE+ LINE - ASSEMBLY KIT VISIO/VISIOWEB-UNITY3.0
Installation Manual UNITY 3.0- Rev. 1.0
e-mail: support@technogym.com
Pag. 28
5. Lift the right lateral guard, beside the di-
splay location, and cut the cable ties that pre-
vent from extracting the High Kit-Low Kit con-
nection cable.
6.Extract the High Kit-Low Kit connection ca-
ble (D) from the frame of the equipment.
WARNING: do not extract the network cable
but only the High Kit-Low Kit connection
cable.
