Technogym EXCITE - Page 35

EXCITE/EXCITE+ LINE - ASSEMBLY KIT VISIO/VISIOWEB-UNITY3.0
Installation Manual UNITY 3.0- Rev. 1.0
e-mail: support@technogym.com
Pag. 35
8.Connect the LAN cable (T) to the CN4 con-
nector of the CPU Board.
9. The gure alongside shows the ON/OFF fan
cable (U) 0WCU0307xx, provided in the kit.
10. Connect the two white fastons of the ON/
OFF Fan cable (U) to the two external metal
sheets of the fan micro-switch.
