© Technosoft 2007 13 IBL2403 Technical Reference
Digital Outputs
All voltages referenced to GND.
Min. Typ. Max. Units
Logic “LOW” -0.5 0 0.2
Logic “HIGH” ; Output current = 0 2.4 4.4 +V
DC
Output voltage
Absolute maximum, duration < 1 ms -1
+V
DC
+
0.5
V
Logic “HIGH”; Load connected to GND 10
Output current
Logic “LOW” 50
mA
ESD Protection
Human Body Model (100 pF, 1.5 kΩ) ±25
KV
Encoder Inputs
Min. Typ. Max. Units
Standards compliance
Differential / TTL / CMOS /
open-collector
Low level input current
Internal 470 Ω pull-ups to +5 V
DC
10 12 mA
Input threshold voltage
In single-ended mode (TTL / CMOS /
/ open-collector)
1.8 1.9 2 V
Input hysteresis 0.1 0.2 0.5 V
Analog Inputs (Ref, Tacho)
Referenced to GND
Min. Typ. Max. Units
Voltage range 0 +5 V
Input impedance 16
KΩ
Resolution 10 bits
Differential linearity Guaranteed 10-bit no-missing-codes 0.09
% FS
1
Offset error
±0.3
% FS
1
Gain error
±5
% FS
1
Bandwidth (-3 dB) 250 Hz
Linear Hall Inputs (LH1, LH2, LH3)
Referenced to GND
Min. Typ. Max. Units
Maximum range 0 +5 V
Voltage range
Operating range Programmable
Input current -0.5 +0.5 mA
Bandwidth (-3 dB) 1 KHz
