© Technosoft 2007 17 IBL2403 Technical Reference
3. Step 1. Hardware Installation
3.1. Mounting
Figure 3.1. IBL2403 drive connectors
The IBL2403 drive was designed to be cooled by natural convection. It can be mounted
horizontally (with label upwards) or vertically inside a cabinet (see Figure 3.2). In both
cases, leave at least 25mm between the drive and surrounding walls/drives, to allow for
free air circulation.
CAUTION !
Before connecting the motor, be sure you have the right
application programmed to E2ROM, else you can damage the
motor and drive. At power-on, the TML application is
automatically executed. See paragraph 3.2.13 to disable this
feature.
