TD350 Series VFD Basic operation instructions
-95-
Function
code
Name
Detailed parameter description
Default
value
25: Ramps reference frequency
(bipolar)
26: Running speed (bipolar)
27: Set value 2 of
EtherCAT/PROFINET/Ethernet IP
communication
28: C_AO1 from PLC (You need to set
P27.00 to 1.)
29: C_AO2 from PLC (You need to set
P27.00 to 1.)
30: Running speed (relative to 2 times
the rotating speed of the motor)
31: Output torque
32–47: Reserved variable
P06.17
Lower limit of AO1 output
-100.0%–P06.19
0.0%
P06.18
Corresponding AO1 output of
lower limit
0.00V–10.00V
0.00V
P06.19
Upper limit of AO1 output
P06.17–100.0%
100.0%
P06.20
Corresponding AO1 output of
upper limit
0.00V–10.00V
10.00V
P06.21
AO1 output filter time
0.000s–10.000s
0.000s
P06.22–
P06.26
Reserved variable
0–65535
0
P06.27
Lower limit of HDO output
-100.0%–P06.29
0.0%
P06.28
Corresponding HDO output of
lower limit
0.00–50.00kHz
0.0kHz
P06.29
Upper limit of HDO output
P06.27–100.0%
100.0%
P06.30
Corresponding HDO output of
upper limit
0.00–50.00kHz
50.00kHz
P06.31
HDO output filter time
0.000s–10.000s
0.000s
5.5.11 Digital input
The TD350 series VFD carries four programmable digital input terminals and two HDI input terminals.
The function of all the digital input terminals can be programmed by function codes. HDI input
terminal can be set to act as high-speed pulse input terminal or common digital input terminal; if it is
set to act as high-speed pulse input terminal, users can also set HDIA or HDIB high-speed pulse input
to serve as the frequency reference and encoder signal input.
