TECHTOP TD350 - Rated Specifications

TD350 Series VFD Product overview
-13-
Field
Sign
Description
Contents
Voltage level
③
Voltage level
2: AC 3PH 200V–240V
Rated voltage: 220V
4: AC 3PH 380V–480V
Rated voltage: 460V
6: AC 3PH 520V–600V
Rated voltage: 575V
*Note: Most 460V models will show HD - Constant Torque (CT) load and ND - Variable Torque (VT)
load data on nameplate. All drives come factory set for HD.
3.6 Rated specifications
3.6.1 AC 3PH 200V–240V
VFD model
Output power
(kW)
Output
horsepower (HP)
Input
current (A)
Output
current (A)
TD350-0R7G-2
0.75
1
5
4.5
TD350-1R5G-2
1.5
2
7.7
7
TD350-2R2G-2
2.2
3
11
10
TD350-004G-2
4
5
17
16
TD350-5R5G-2
5.5
7.5
21
20
TD350-7R5G-2
7.5
10
31
30
TD350-011G-2
11
15
43
42
TD350-015G-2
15
20
56
55
TD350-018G-2
18.5
25
71
70
TD350-022G-2
22
30
81
80
TD350-030G-2
30
40
112
110
TD350-037G-2
37
50
132
130
TD350-045G-2
45
60
163
160
TD350-055G-2
55
75
200
200
Note:
 The input current of 0.75–55 kW VFDs is measured at the input voltage of 220V without reactors.
 The rated output current is the output current measured at the output voltage of 220V.
 Within the allowable input voltage range, the output current/power cannot exceed the rated output
current/power.
 Unless otherwise specified, the "**kW" described in this manual refers to the power of the HD (CT)
models. For VFDs of 75, 132, and 500 kW, HD (CT) and ND (VT) models must be distinguished.
