TD350 Series VFD Basic operation instructions
-53-
5.5 Basic operation instruction
5.5.1 What this section contains
This section introduces the function modules inside the VFD
 Ensure all the terminals are fixed and tightened firmly.
 Ensure the motor matches with the VFD power.
5.5.2 Common commissioning procedures
The common operation procedures are shown below (take motor 1 as an example).
Start
Power up after confirming the
wiring is correct
Restore to default value
(P00.18=1)
Set the motor parameters of
P02.01–P02.05 as per the
motor nameplate
Set the motor parameters of
P02.15–P02.19 as per the
motor nameplate
Press QUICK/JOG to jog
If the motor rotates in wrong direction, power off
and exchange the motor wires of any two phases,
and power on again
Set autotuning mode
(P00.15)
Set P00.15=1 to implement
rotating autotuning
Set P00.15=3 to implement
static autotuning 2
Start autotuning after pressing
RUN key, and stop after
autotuning is done
Set running frequency
Set speed running control
mode (P00.00)
SVC 1 (P00.00=0) SVC 2 (P00.00=1) V/F control mode (P00.00=2)
Set vector control parameters
in P03 group
Set vector control parameters
in P03 group
Set V/F parameters in P04
group
Set start/stop control
parameters in P01 group
Give the running command to
run the machine
Give the stop command to
stop the machine
End
Set running command channel
(P00.01, P00.02)
Set P00.15=2 to implement
static autotuning 1
Asynchronous motor
Synchronous motor
Note: If fault occurred, rule out the fault cause according to "fault tracking".
