TECHTOP TD350 - Grid Specifications; Motor Connection Data; Application Standards

-332-
B.3 Grid specifications
Grid voltage
AC 3PH 380V–480V
Allowable voltage
fluctuation
-15%–10%
Frequency
50/60 Hz±5%, with a maximum change rate of 20%/s
B.4 Motor connection data
Motor type
Asynchronous induction motor or permanent-magnet synchronous
motor
Voltage
0–U1 (rated voltage of the motor), 3PH symmetrical, Umax (rated
voltage of the VFD) at the field-weakening point
Short-circuit protection
The short-circuit protection for the motor output meets the
requirements of IEC 61800-5-1.
Frequency
0–400 Hz
Frequency resolution
0.01 Hz
Current
See Rated specifications.
Power limit
1.5 times of the rated power of the motor
Field-weakening point
10–400 Hz
Carrier frequency
4, 8, 12, or 15 kHz
B.4.1 EMC compatibility and motor cable length
The following table describes the maximum motor cable lengths that meet the requirements of the EU
EMC directive (2004/108/EC) when the carrier frequency is 4 kHz.
All models (with external EMC filters)
Maximum motor cable length (m)
Environment category II (C3)
30
You can learn the maximum length of the motor cable through the running parameters of the VFD. To
understand the accurate maximum cable length for using an external EMC filter, contact the local
TECHTOP office.
For description about the environments categories I (C2) and II (C3), see Section B.6 "EMC
regulations".
B.5 Application standards
The following table describes the standards that the VFDs comply with.
EN/ISO 13849-1
Safety of machinery––Safety-related parts of control systems––Part
1: General principles for design
IEC/EN 60204-1
Safety of machinery––Electrical equipment of machines. Part 1:
General requirements
IEC/EN 62061
Safety of machinery––Safety-related functional safety of electrical,
electronic, and programmable electronic control systems
IEC/EN 61800-3
Adjustable speed electrical power drive systems––Part 3:EMC
requirements and specific test methods
