TECHTOP TD350 - Keypad Operation

TD350 Series VFD Basic operation instructions
-41-
01: TD350
16:02:35
Fwd
Local Fault
Homepage
Confirm
Fault code：
19：Current detection fault (ItE)
Present fault type:
19
Fig 5.7 Fault alarm display state
5.4 Keypad operation
Various operations can be performed on the VFD, including entering/exiting menu, parameter
selection, list modification and parameter addition.
5.4.1 Enter/exit menu
Regarding the monitoring menu, the operation relation between enter and exit is shown below.
01: TD350
16:02:35
Fwd
Local Ready
Motor Speed
P17.05 rmp
0
Outp Cur
P17.04 A
0.0
0.00
AboutMonitor
Menu
OutpFreq
P17.01 Hz
16:02:35
Stop state display parameter
Running state display parameter
01: TD350
16:02:35
HomepageReturn
Select
Home monitoring parameter setting
01: TD350
Fwd
Local Ready
HomepageReturn
Select
Fwd
Local Ready
Fig 5.8 Enter/exit menu diagram 1
Regarding the system menu, the operation relation between entry and exit is shown below.
