TD350 Series VFD Dimension drawings
-335-
Appendix C Dimension drawings
C.1 What this chapter contains
This chapter describes the dimension drawings of TD350 series VFDs. The dimension unit used in
the drawings is mm.
C.2 Keypad structure
C.2.1 Structure diagram
Installation hole dimensions and diagram for key installation without bracket
Ou
ter outline
of the keypad
2
-
M
3
×
8
tapping
screw
Panel
Keypad
109.3
71.3
28.5
16.8
2.5
109.3
56
6.7
71.3
58
2- ø4
1934.4
19
20.4
Fig C.1 Keypad structure diagram
C.2.2 Keypad installation bracket
Note: When installing a keypad in a position away from the VFD, you can directly use M3 threaded
screws or a keypad bracket. For VFDs of 220V, 0.75 to 15 kW and 460V, 1.5 to 30 kW, you need to
use optional keypad installation brackets. For those of 220V, 18 to 55 kW, 460V, 37 to 500 kW, and
575V, 18.5 to 110 kW, you can use optional brackets or use the standard keypad brackets externally.
Installation dimensionsKeypad adapter bracket
103
98
140
115
4-R12
Fig C.2 Keypad installation bracket
