TECHTOP TD350 - PID Control

TD350 Series VFD Basic operation instructions
-117-
Function
code
Name
Detailed parameter description
Default
value
P09.03
PID output characteristics
0: PID output is positive characteristic
1: PID output is negative characteristic
0
P09.04
Proportional gain (Kp)
0.00–100.00
1.80
P09.05
Integral time (Ti)
0.01–10.00s
0.90s
P09.06
Derivative time (Td)
0.00–10.00s
0.00s
P09.07
Sampling cycle (T)
0.000–10.000s
0.100s
P09.08
Limit of PID control
deviation
0.0–100.0%
0.0%
P09.09
Upper limit value of PID
output
P09.10–100.0% (max. frequency or
voltage)
100.0%
P09.10
Lower limit value of PID
output
-100.0%–P09.09 (max. frequency or
voltage)
0.0%
P09.11
Feedback offline detection
value
0.0–100.0%
0.0%
P09.12
Feedback offline detection
time
0.0–3600.0s
1.0s
P09.13
PID control selection
0x0000–0x1111
Ones:
0: Continue integral control after the
frequency reaches upper/lower limit
1: Stop integral control after the
frequency reaches upper/lower limit
Tens:
0: The same with the main reference
direction
1: Contrary to the main reference
direction
Hundreds:
0: Limit as per the max. frequency
1: Limit as per A frequency
Thousands:
0: A+B frequency, acceleration
/deceleration of main reference A
frequency source buffering is invalid
1: A+B frequency, acceleration/
deceleration of main reference A
frequency source buffering is valid,
acceleration/deceleration is determined
by P08.04 (acceleration time 4).
0x0001
