TD350 Series VFD Basic operation instructions
-119-
Function
code
Name
Detailed parameter description
Default
value
13: Set via
EtherCAT/PROFINET/Ethernet IP
communication
14: Set via PLC card
P00.11
Acceleration time 1
0.0–3600.0s
Depend
on model
P00.12
Deceleration time 1
0.0–3600.0s
Depend
on model
P05.01–
P05.06
Digital input function
selection
26: Wobbling frequency pause (stop at
current frequency)
27: Wobbling frequency reset (revert to
center frequency)
/
P08.15
Amplitude of wobbling
frequency
0.0–100.0% (relative to set frequency)
0.0%
P08.16
Amplitude of jump frequency
0.0–50.0% (relative to amplitude of
wobbling frequency)
0.0%
P08.17
Wobbling frequency rise
time
0.1–3600.0s
5.0s
P08.18
Wobbling frequency fall time
0.1–3600.0s
5.0s
5.5.17 Local encoder input
The TD350 series VFD supports pulse count function by inputting the count pulse from HDI
high-speed pulse port. When the actual count value is no less than the set value, digital output
terminal will output count-value-reached pulse signal, and the corresponding count value will be
zeroed out.
Function
code
Name
Detailed parameter description
Default
value
P05.00
HDI input type
0x00–0x11
Ones: HDIA input type
0: HDIA is high-speed pulse input
1: HDIA is digital input
Tens: HDIB input type
0: HDIB is high-speed pulse input
1: HDIB is digital input
0x00
P05.38
HDIA high-speed pulse input
function
0: Set input via frequency
1: Reserved
2: Input via encoder, used in combination
with HDIB
0
