TD350 Series VFD Function parameter list
-154-
Detailed parameter description
V/F frequency
point 2 of motor 2
voltage of motor 2)
Setting range of P04.18: P04.16–P04.20
Setting range of P04.19: 0.0%–110.0% (rated
voltage of motor 2)
Setting range of P04.20: P04.18–P12.02 (rated
frequency of asynchronous motor 2) or P04.18–
P12.16 (rated frequency of synchronous motor 2)
Setting range of P04.21:0.0%–110.0%(rated
voltage of motor 2)
V/F voltage point
2 of motor 2
V/F frequency
point 3 of motor 2
V/F voltage point
3 of motor 2
V/F slip
compensation
gain of motor 2
This parameter is used to compensate for the motor
rotating speed change caused by load change in
the SVPWM mode, and thus improve the rigidity of
the mechanical characteristics of the motor. You
need to calculate the rated slip frequency of the
motor as follows:
△f=fb-n*p/60
where fb is the rated frequency of motor 2,
corresponding to P12.02; n is the rated speed of
motor 2, corresponding to P12.03; p is the number
of pole pairs of motor 2. 100% corresponds to the
rated slip frequency △f of motor 2.
Setting range: 0.0–200.0%
Low-frequency
oscillation control
factor of motor 2
In the SVPWM mode, current oscillation may easily
occur on motors, especially large-power motors, at
some frequency, which may cause unstable running
of motors or even overcurrent of VFDs. You can
modify this parameter to prevent current oscillation.
Setting range of P04.23: 0–100
Setting range of P04.24: 0–100
Setting range of P04.25: 0.00 Hz–P00.03 (Max.
output frequency)
High-frequency
oscillation control
factor of motor 2
Oscillation
control threshold
of motor 2
0: No action
1: Automatic energy-saving operation
Under light-load state, the motor can adjust the
output voltage automatically to achieve
energy-saving purpose
Channel of
voltage setting
0: Keypad; output voltage is determined by P04.28
1: AI1
2: AI2
