TD350 Series VFD Product overview
-15-
3.6.3 AC 3PH 520V–600V
VFD model
Output power
(kW)
Output
horsepower
(HP)
Input current
(A)
Output current
(A)
TD350-0R7G-6
0.75
1
3.3
2.1
TD350-1R5G-6
1.5
2
5
3.2
TD350-2R2G-6
2.2
3
7
4.5
TD350-004G-6
4
5
10
6.5
TD350-5R5G-6
5.5
7.5
13
9
TD350-7R5G-6
7.5
10
16.5
12
TD350-011G-6
11
15
19
16
TD350-015G-6
15
20
24
21
TD350-018G-6
18.5
25
29
27
TD350-022G-6
22
30
40
35
TD350-030G-6
30
40
47
45
TD350-037G-6
37
50
52
52
TD350-045G-6
45
60
65
62
TD350-055G-6
55
75
85
86
TD350-075G-6
75
100
95
98
TD350-090G-6
90
125
118
120
TD350-110G-6
110
150
145
150
Note:
 The input current of 0.75–110kW VFDs is measured at the input voltage of 575V without
reactors.
 The rated output current is the output current measured at the output voltage of 575V.
 Within the allowable input voltage range, the output current/power cannot exceed the rated
output current/power.
 Unless otherwise specified, the "**kW" described in this manual refers to the power of the HD
(CT) models. For VFDs of 75, 132, and 500 kW, HD (CT) and ND (VT) models must be
distinguished.
