TECHTOP TD350 - Page 294

TD350 Series VFD Extension cards
-289-
EC-PC 5 02-00
① ② ③ ④ ⑤
Field identifier
Field description
Naming example
①
Product category
EC: Extension card
②
Card category
IO: IO extension card
TX: Communication extension card
PG: PG card
PC: PLC programmable card
③
Technical version
Indicates the generation of a technical version by
using odd numbers, for example, 1, 3, and 5
indicate the 1
st
, 2
nd
, and 3
rd
generations of the
technical version.
④
Distinguishing code
01: 10 points, with 6 inputs and 4 outputs (2
transistor outputs + 2 relay outputs)
02: 8 points of IO, 1 point of AI, 1 point of AO, and 1
point of RS485 communication
03: Reserved
⑤
Special requirement
Reserved. The default value is 00.
EC-TX 5 01 B
①
②
③ ④
⑤
Field identifier
Field description
Naming example
①
Product category
EC: Extension card
②
Card category
TX: Communication extension card
PG: PG card
PC: PLC programmable card
IO: IO extension card
③
Technical version
Indicates the generation of a technical version by
using odd numbers, for example, 1, 3, and 5
indicate the 1
st
, 2
nd
, and 3
rd
generations of the
technical version.
④
Distinguishing code
01: Bluetooth communication card
02: WIFI communication card
03: PROFIBUS communication card
05: Canopen communication card
