TD350 Series VFD Extension cards
-302-
Category
Symbol
Name
Function
Common
terminal/ground
COM
Common terminal
of +24V
Common terminal of +24V. If PS1 is
connected, COM indicates PS1 is
connected.
GND
Analog ground
Reference zero potential of +10V
PE
Protective earthing
terminal
Protective earthing terminal
Digital input
PS1—COM
Digital input 1
1. Internal impedance: 4kΩ
2. Accept 12–30V voltage input
3. Bi-directional input terminal
4. Max. input frequency: 1kHz
5. Both source and sink inputs are allowed,
but the input types must be the same
PS2—COM
Digital input 2
PS3—COM
Digital input 3
PS4—COM
Digital input 4
PS5—COM
Digital input 5
PS6—COM
Digital input 6
Analog input and
output
AI1
Analog input 1
1. Input range: AI1 voltage and current
range: 0–10V, 0–20mA
2. Input impedance: 20kΩ during voltage
input; 250Ω during current input
3. Voltage or current input is set through
the jumper.
4. Resolution ratio: When 10V corresponds
to 50Hz, the min. resolution ratio is 5mV
5. Deviation: ±1% when the input reaches
full the measurement range at 25°C
AO1
Analog output 1
1. Output range: 0–10V voltage or 0–20mA
current
2. Voltage or current output is set through
the jumper.
3. Deviation: ±1% when the input reaches
full the measurement range at 25°C.
Relay output
PRO1A
NO contact of relay
1
1. Contact capacity: 2A/AC250V,
1A/DC30V
2. Unable to function as high frequency
switch output
PRO1C
Common contact of
relay 1
PRO2A
NO contact of relay
2
PRO2C
Common contact of
relay 2
