TECHTOP TD350 - Appendix C Dimension Drawings; Keypad Structure

TD350 Series VFD Dimension drawings
-338-
W1
H1
D1
W2 W2
6- ø11.0
H2
Fig C.7 Wall-mounting diagram of VFDs of 460V 132–200 kW
Table C.1 Wall-mounting dimensions of 220V 0.75–55kW (unit: mm)
VFD
specification
W1
W2
H1
H2
D1
Installation hole
0.75kW
126
115
186
175
185
Ø 5
1.5kW–2.2kW
146
131
256
243.5
192
Ø 5
4kW–5.5kW
170
151
320
303.5
219
Ø 6
7.5kW
230
210
330
311
217
Ø 6
11kW–15kW
255
237
400
384
242
Ø 7
18.5kW–30kW
270
130
555
540
325
Ø 7
37kW–55kW
325
200
680
661
365
Ø 9.5
Table C.2 Wall-mounting dimensions of 460V VFDs (unit: mm)
VFD
specification
W1
W2
W3
H1
H2
D1
Installation hole
1.5kW–2.2kW
126
115
-
186
175
185
Ø 5
4kW–5.5kW
146
131
-
256
243.5
192
Ø 5
7.5kW-11kW
170
151
-
320
303.5
219
Ø 6
15kW–18.5kW
230
210
-
330
311
217
Ø 6
22kW–30kW
255
237
-
400
384
242
Ø 7
37kW–55kW
270
130
-
555
540
325
Ø 7
75kW–110kW
325
200
-
680
661
365
Ø 9.5
132kW–200kW
500
180
-
870
850
360
Ø 11
