TECHTOP TD350 - Appendix D Optional Peripheral Accessories; Wiring of Peripheral Accessories

TD350 Series VFD Optional peripheral accessories
-349-
VFD model
Recommended cable size
(AWG)
Required torque (in-lbs)
Wire
connector
(##)
R, S, T; U, V, W;
P1, (+), PB, (-)
PE
R, S, T; U, V, W;
P1, (+), PB, (-)
PE
TD350-5R5G-6
12AWG
12AWG
20 or 25 @@
15
Optional
TD350-7R5G-6
10AWG
10AWG
20 or 25 @@
15
Optional
TD350-011G-6
10AWG
10AWG
20
15
Optional
TD350-015G-6
10AWG
10AWG
20
15
Optional
TD350-018G-6
8AWG
10AWG
20
15
Optional
TD350-022G-6
4AWG
8AWG
22 or 60 or 49.5
##
10
Required
TD350-030G-6
TD350-037G-6
TD350-045G-6
3/0AWG
2AWG
60
10
Required
TD350-055G-6
TD350-075G-6
TD350-090G-6
TD350-110G-6
Control terminal block
26-14(Str/Sol)
AWG
--
4.5
--
Optional
Note:
 It is appropriate to use the recommended cable size at 40℃ and rated current. The wiring
distance cannot be more than 100m.
 Terminals P1, (+), PB and (-) connect the DC reactor options and parts.
 Use 75˚C CU wire only for field input and output wire.
 Note "@@":
Using SUCCEED's Terminal Block: "Tightening Torque shall be 20 in-lb" or equivalent.
Using DEGSON's Terminal Block: "Tightening Torque shall be 25 in-lb" or equivalent.
 Note "$$":
Using SUCCEED's Terminal Block: "Tightening Torque shall be 60 in-lb" or equivalent.
Using DEGSON's Terminal Block: "Tightening Torque shall be 80 in-lb" or equivalent
 Note "##":
Using SUCCEED's Terminal Block: "Tightening Torque shall be 22 in-lb" or equivalent.
Using DEGSON's Terminal Block: "Tightening Torque shall be 60 in-lb" or equivalent.
Using CONNECTION's Terminal Block: "Tightening Torque shall be 49.5 in-lb" or equivalent.
