Detailed parameter description
Source of upper
limit setting of the
torque during
motoring
0: Keypad (P03.20)
1: AI1 (100% relative to three times of motor
current)
2: AI2 (the same as above)
3: AI3 (the same as above)
4: Pulse frequency HDIA (the same as above)
5: Modbus/Modbus TCP communication (the
same as above)
6: PROFIBUS/CANopen/DeviceNet
communication (the same as above)
7: Ethernet communication (the same as above)
8: Pulse frequency HDIB (the same as above)
9: EtherCAT/PROFINET/Ethernet IP
communication
10: PLC
11: Reserved
Note: Source 1–10, 100% relative to three times
of motor current.
Source of upper
limit setting of
brake torque
0: Keypad (P03.21)
1: AI1 (100% relative to three times of motor
current)
2: AI2 (the same as above)
3: AI3 (the same as above)
4: Pulse frequency HDIA (the same as above)
5: Modbus/Modbus TCP communication (the
same as above)
6: PROFIBUS/CANopen/DeviceNet
communication (the same as above)
7: Ethernet communication (the same as above)
8: Pulse frequency HDIB (the same as above)
9: EtherCAT/PROFINET/Ethernet IP
communication
10: PLC
11: Reserved
Note: Source 1–10, 100% relative to three times
of motor current.
Set upper limit of
the torque when
motoring via
keypad
0.0–300.0% (rated motor current)
