TD350 Series VFD Basic operation instructions
-91-
Function
code
Name
Detailed parameter description
Default
value
P05.41
Upper limit frequency of
HDIA
P05.39 –50.000KHz
50.000KHz
P05.42
Corresponding setting of
upper limit frequency of
HDIA
-100.0%–100.0%
100.0%
P05.43
HDIA frequency input filter
time
0.000s–10.000s
0.030s
P05.44
HDIB high-speed pulse input
function selection
0: Set input via frequency
1: Reserved
2: Input via encoder, used in
combination with HDIA
0
P05.45
Lower limit frequency of
HDIB
0.000 KHz – P05.47
0.000KHz
P05.46
Corresponding setting of
lower limit frequency of HDIB
-100.0%–100.0%
0.0%
P05.47
Upper limit frequency of
HDIB
P05.45 –50.000KHz
50.000KHz
P05.48
Corresponding setting of
upper limit frequency of
HDIB
-100.0%–100.0%
100.0%
P05.49
HDIB frequency input filter
time
0.000s–10.000s
0.030s
P05.50
AI1 input signal type
0–1
0: Voltage type
1: Current type
0
5.5.10 Analog output
The TD350 series VFD carries one analog output terminal (0–10V/0–20mA) and one high-speed
pulse output terminal. Analog output signals can be filtered separately, and the proportional relation
can be adjusted by setting the max. value, min. value, and the percentage of their corresponding
output. Analog output signal can output motor speed, output frequency, output current, motor torque
and motor power at a certain proportion.
