TD350 Series VFD Basic operation instructions
-93-
Set value
Function
Description
17
Set value 2 of
PROFIBUS\CANopen/DeviceNet
communication
-1000–1000, 1000 corresponds to 100.0%
18
Set value 1 of Ethernet
communication
-1000–1000, 1000 corresponds to 100.0%
19
Set value 2 of Ethernet
communication
-1000–1000, 1000 corresponds to 100.0%
20
Input value of high-speed pulse
HDIB
0.00–50.00kHz
21
Reserved variable
22
Torque current (bipolar, 100%
corresponds to 10V)
0–Two times of rated current of motor
23
Exciting current (100%
corresponds to 10V)
0–One times of rated current of motor
24
Set frequency (bipolar)
0–Max. output frequency
25
Ramps reference frequency
(bipolar)
0–Max. output frequency
26
Running speed (bipolar)
0–Max. output frequency
27
Set value 2 of
EtherCAT/PROFINET /Ethernet
IP communication
-1000–1000, 1000 corresponds to 100.0%
28
C_AO1 from PLC
1000 corresponds to 100.0%
29
C_AO2 from PLC
1000 corresponds to 100.0%
30
Running speed
0–Two times of rated synchronous speed of motor
31–47
Reserved variable
Related parameter list:
Function
code
Name
Detailed parameter description
Default
value
P06.00
HDO output type
0: Open collector high-speed pulse
output
1: Open collector output
0
P06.14
AO1 output selection
0: Running frequency
1: Set frequency
2: Ramps reference frequency
3: Running speed
4: Output current (relative to 2 times the
rated current of the VFD)
0
P06.15
Reserved variable
0
P06.16
HDO high-speed pulse output
0
