AFMS N°D03 FOR ALTERNATIVE AVIONICS CONFIGURATION
Section 3 – Emergency procedures
AVIONIC SUITE FAILURES
3. G500 SYSTEM FAILURES
3.1 LOSS OF INFORMATION DISPLAYED
When a LRU or a LRU function fails, a large red „X‟ is typically displayed on
the display field associated with the failed data.
In most of cases, the red “X” annunciation is accompanied by a
message advisory alert issuing a flashing ADVISORY Softkey
annunciation which, once selected, acknowledges the presence
of the message advisory alert and displays the alert text message
in the Alerts Window.
3.2 LOSS OF AIRSPEED INFORMATION
AIRSPEED FAIL
(RED X ON DISPLAY FIELD)
Display system is not receiving airspeed input
from Air Data Computer.
INSTRUCTION: revert to standby instrument
