AFMS N°D07 FOR GARMIN GFC700 AUTOPILOT AND VARIABLE PITCH PROPELLER EQUIPPED
AEROPLANES
Section 1 – General-
AUTOPILOT DESCRIPTION
12. AUTOPILOT DESCRIPTION
P2010 aircraft is equipped, as an optional equipment, with an integrated 2-axis autopilot
suite manufactured by Garmin and identified as GFC 700. This autopilot suite was de-
signed as an option for the G1000 integrated flight deck. The autopilot is controlled via
dedicated keys grouped in a control panel located on the MFD. The installed MFD dis-
play is different with respect to standard P2010 configuration since it is GDU 1044.
The autopilot suite installed on P2010 is based on the following configuration:
• 1 Roll servo
• 1 Pitch servo
• 1 Pitch Trim servo
Neither yaw axis nor rudder trim tab control is provided.
The autopilot is connected to electric system through the below listed circuit breakers
connected to the avionics bus:
1) A/P (5A)
2) PITCH TRIM (3A)
The installed servos are capstan type and are composed of two main components:
• A servo motor
• A servo capstan including the servo clutch
The following block diagram describes the avionic system installed on P2010 and its in-
terconnections with the autopilot servos:
