TECO E310 Series - Chapter 4: Software and Parameter Configuration; Keypad Operation and Display

4-1
Chapter 4 Software Index
4.1 Keypad Description
4.1.1Keypad Display and Operation Instruction
1. Four actions of FUN mode： Hz/RPM, and display of five 7-segment display. (Refer to operation
description of the keypad).
2. FWD LED： Forward Direction, LED action (Flash while stopped, solid Lit during operation).
3. REV LED： Reverse Direction, LED action (Flash while stopped, solid Lit during operation).
Caution
To avoid keypad damage, do not operate it with a screwdriver or any sharp and hard tool.
Figure 4-1 Keypad Layout
