N3 Drive Operations Manual
A (Advanced) Parameter Details; A081 – A091 60
A081
Auto_Run Stop
1
0000: Stop
0001: Forward
0002: Reverse
A082
2
A083
3
A084
4
A085
5
A086
6
A087
7
A088
8
A091
Operation Mode Selection During
Auto Run
0000: Auto Run Mode Not Effective
0001: Auto Run mode for one cycle. (continue
running from the
unfinished step if restarting)
0002: Auto Run mode is performed
periodically (continue running from
the unfinished step if restarting)
0003: Auto Run mode for one cycle,
then hold the speed of final
step to run. (continue
running from the unfinished
step if restarting)
0004: Auto Run mode for one cycle.
(starting a new cycle if restarting)
0005: Auto Run mode is performed
periodically (starting a new cycle if
restarting)
0006: Auto Run mode for one single cycle,
then hold the speed of final step to
run. (starting a new cycle if
restarting)
1.) A091 = 0000 – 0006: Selects the mode of operation in Auto_Run.
2.) In the Auto_Run mode:
A061 - A068: Selects the run frequency
A071 - A078: Selects the time of the run frequency
A081 - A088: Selects the direction (Fwd / Rev) of the output or the Stop mode.
3.) In the Auto_Run mode the acceleration / deceleration follow the settings of b007 / b008.
4.) In the auto_Run mode, the multi-step frequency commands 02 - 04 are ineffective.
5.) Some examples of the Auto_Run mode are as follows:
(A) Single Cycle Running - (A091= 0001and 0004)
In this example, the inverter will run for a single full cycle based upon the specified settings in the table and then stop.
Cont.
Cmd / Sel
Freq Cmd. Hz
Oper Sel. Sec.
Fwd / Rev / Stop
1
A061 = 15
A071 = 20
A081 = Fwd.
2
A062 = 30
A072 = 25
A082 = Fwd.
3
A063 = 50
A073 = 30
A083 = Fwd.
4
A064 = 20
A074 = 40
A084 = Rev.
5 - 8
A065 – A068 = 0
A075 – A078 = 0
A085 – A088 = 0
