4-9
Group 01- External terminal digital signal input function group
Code
Parameter Name Setting Range Default Unit
Attribute
01-00
Multifunction Input Term. S1
0: Forward/Stop Command 0 -
01-01
Multifunction Input Term. S2
1: Reverse/Stop Command 1 -
01-02
Multifunction Input Term. S3
2: Preset Speed unit 0 (3-02) 5 -
01-03
Multifunction Input Term. S4
3: Preset Speed unit 1 (3-03) 6 -
01-04
Multifunction Input Term. S5
4: Preset Speed unit 2 (3-05)
8
-
5: Jog Command
6: Emergency Stop(decelerate to zero
and stop)
7: Base Block (rotation freely to stop)
8: Fault Reset (RESET)
9: Auto Running Mode
10: Speed up
11: Slow Down
12: Pulse input
- Pulse width measurement (S5)
13: Pulse input
- Frequency measurement (S5)
14: UP Frequency Increasing Command
15: DOWN Frequency Decreasing
Command
01-05
Speed up / Slow Down Value
0～ 100 20 %
01-06
Multifunction terminal S1~ S5
confirm the scan times
1~200 10 2mS
01-07
UP/DOWN Frequency
Detection Width
0.00~5.00 0.00 Hz
01-08
UP/DOWN Frequency
Hold/Adjust Selection
When an increase/decrease frequency
command is used, when the converter
stops running, the set frequency will be
maintained.
0
-
1: The setting frequency will be
normalized to 0 Hz
2: The setting frequency will be
maintained, and the increase/decrease
frequency function will be effective
when the machine stops.
01-09
Output Relay RY1 Operation
mode
0: Run
0
-
1: Frequency Reached (Running
Frequency Reached setting value)
2: Fault
3: Any Frequency matches (1-11±1-12)
4: Frequency Threshold Level
(> 1-11) - Frequency Reached 1
5: Frequency Threshold Level
(> 1-11) - Frequency Reached 2
6: Setting value reached
7:
Current value reached
01-10
Relay output contact mode
0:A contact ( Normal open)
0
1:B contact ( Normal close)
01-11
Frequency Output Setting (Hz)
0.00~400.00 0.00 Hz *1
01-12
Frequency Detection Range
0.00~30.0040 2.00 Hz *1
01-13
S1~ S5 switch type select
NO(Normal open)
NC(Normal close)
xxxx0: s1 NO xxxx1: s1 NC
00000
xxx0x: s2 NO xxx1x: s2 NC
xx0xx: s3 NO xx1xx: s3 NC
x0xxx: s4 NO x1xxx: s4 NC
0xxxx: s5 NO 1xxxx: s5 NC
01-14
Input pulse frequency (Pulse
width measurement)
0.01~0.20 0.1 kHz
