4-10
Group 01- External terminal digital signal input function group
Code
Parameter Name Setting Range Default Unit
Attribute
01-15
Pulse frequency multiple
0.01~9.99 1.00
01-16
Pulse input filtering
coefficient
0~100 5
01-17
Count value reaches the
setting value
0~9999 0
01-18
Pulse input counting filtering
coefficient
1~100 1
01-19
Current reaches the alignment
0.1~15.0 0.1 A
01-20
Current arrives to detect the
delay time
0.1~15.0 0.1 Sec
Group
External terminal analog signal input function group
Code
Parameter Name Setting Range Default Unit Attribute
02-00
AVI(AIN) and ACI
analog Input signal type
select
value AVI(AIN) ACI
0
-
0
0~10V
or(0~20mA)
0~20mA
1
0~10V
or(0~20mA)
4~20mA
2
2~10V
or(4~20mA)
0~20mA
3
2~10V
or(4~20mA)
4~20mA
02-01
AVI(AIN) signal
scanning and filtering
time
1~200 100 2mSec
02-02
AVI(AIN) Gain
0 ~ 200 100 % *1
02-03
AVI(AIN) Bias
0 ~ 100 0 % *1
02-04
AVI(AIN) Bias Selection
0: Positive 1: Negative
0 - *1
02-05
AVI(AIN) signal
directional control
selection
0: Positive 1: Negative
0 - *1
02-06
ACI Function
selection
0:PID feedback signal (terminal ACI)
1:ACI deviation signal input (terminal ACI)
0
02-07
ACI signal scanning
and filtering time
1~200 100 2mSec
02-08
ACI Gain
0 ~ 200 100 % *1
02-09
ACI Bias
0 ~ 100 0 % *1
02-10
ACI Bias Selection 0: Positive 1: Negative
0 - *1
02-11
ACI signal directional
control selection
0: Positive 1: Negative
0 - *1
02-12
Analog Output
mode(FM+)
0: Output Frequency
0 - *1
1: Frequency Setting
2: Output Voltage
3: DC Bus Voltage
4: Output Current
02-13
Analog Output Gain
0 ~ 200 100 % *1
02-14
Analog Output filtering
coefficient
0 ~ 100 5 % *1
To Next Page
