TECO S310+ Series User Manual

4-15
Group
09
-
PID Parameters
Code Parameter Name Setting Range Default Unit Attribute
09-00
PID mode selection
4：Feedback D Control
(Fwd/Rev, Reversed Characteristics)
0
09-01
Feedback Gain coefficient
0.00 ~ 10.00 1.00
*1
09-02
Proportional Gain
0.0 ~ 10.0 1.0 %
09-03
Integral Time
0.0 ~ 100.0 10.0 Sec
09-04
Differential Time
0.00 ~ 10.00 0.00 Sec
09-05
PID Offset
0: Positive
0
1: Negative
09-06
PID Offset Adjust
0 ~109 0 %
09-07
PID Output Lag Filter Time
0.0 ~ 2.5 0.0 Sec
09-08
Feedback Loss Detection Mode
0：Disabled
0
1：Enabled - Drive Continues to
Operate After Feedback Loss
2：Enabled - Drive "STOPS"
After Feedback Loss
09-09
Feedback Loss Detection Level
0 ~ 100 0
09-10
Feedback Loss Detection Delay
Time
0.0 ~25.5 1.0 Sec
09-11
Integration Limit Value
0 ~ 109 100
09-12~09-13 Reserved
09-14
Sleep Frequency Level
0.00~400.00 0.00 Hz
09-15
Sleep Function Delay Time
0.0 ~25.5 0.0 Sec
09-16
Wake up frequency Level
0.00 ~ 400.00 0.00 Hz
09-17
Wake up function Delay Time
0.0 ~ 25.5 0.0 Sec
Group
1
0
-
Assistant function group
Code Parameter Name Setting Range Default Unit Attribute
10-01
Reverse operation control
0: Reverse command is enabled
0
1: Reverse command is disabled
10-02 Reserved
10-03
Carrier Frequency 1~12 5 kHz
10-04
Carrier mode Selection
0: Carrier mode 0
1
1: Carrier mode 1
10-05~10-06 Reserved
10-07
S-Curve Acc/Dec 1
0.0 ~4.0 0.0 Sec
10-08
S-Curve Acc/Dec
0.0 ~ 4.0 0.0 Sec
10-09
S-Curve Acc/Dec 3
0.0 ~ 4.0 0.0 Sec
10-10
S-Curve Acc/Dec 4
0.0 ~ 4.0 0.0 Sec
10-11~10-15 Reserved
10-16
Automatic Voltage
Regulation (AVR)
0: Enable
0
1: Disable
10-17
Carrier Output Tuning
with temperature
0: Enable
0
1: Disable
