4-14
Group 07- Protection Parameters
Code
Parameter Name Setting Range Default Unit Attribute
07-03
Stall Prevention Level In Run
Mode (%)
50 ~ 200 160 %
07-04
over voltage Prevention Level in
Run Mode (%)
80~100 （OV %） 100 %
07-05
Electronic Motor Overload
Protection Operation Mode OL1
0: Enable motor Protect by relay
1 -
1: Disable motor Protect by relay
07-06~07-12 Reserved
07-13
OH over heat Protection
( cooling fan control)
0: Auto (Depends on temp.)
1 -
1: Operate while in RUN mode
2: Always Run
3: Disabled
07-14~07-17 Reserved
07-18
OL2 protection reset time
1.0~10.0 5.0
Group
Communication function group
Code Parameter Name Setting Range Default Unit
Attribute
08-00
Assigned Communication
Station Number
1~ 32 1 - *2*3
08-01
RTU/ASCII slection
0：RTU code
0 *2*3
1：ASCII code
08-02
Baud Rate Setting (bps)
0:2400
3 bps
*2*3
1:4800
2:9600
3:19200
4:38400
08-03
Stop Bit Selection
0: 1 Stop Bit
0 - *2*3
1: 2 Stop Bits
08-04
Parity Selection
0: Without Parity
0 - *2*3
1: With Even Parity
2: With Odd Parity
08-05
Data Format Selection
0: 8-Bits Data
1: 7-Bits Data
0 - *2*3
1: 7-Bits Data
08-06
Communication time-out
detection time
0.0~25.5 0.0 Sec
08-07
Communication time-out
operation selection
0: Deceleration to stop
0 -
1: Coast to stop
2: continue operating.
08-08
Err6 fault tolerance times
1~20 3
Group
PID Parameters
Code
Parameter Name Setting Range Default Unit
Attribute
09-00
PID mode selection
0：Disable
0
1：Bias D Control
(Fwd/Rev,positive Characteristics)
2：Feedback D Control
(Fwd/Rev ,positive Characteristics)
3.Bias D Control
(Fwd/Rev, Reversed Characteristics)
To Next Page
