DATA
High 17H
Low 70H
CRC-16
High CBH
Low 26H
* DATA Numbers are the actual number timers 2
6.Comparison list between parameter and register
Note：
Parameter register No.: GGnnH，“GG”means Group number ，“nn” means Parameter number
for example: the address of Pr 08-03 is 0803H. the address of Pr 10-11 is 0A0BH
Register
No.
Function Register
No.
Function Register No. Function
Group00 Group01 Group02
0000H
Reserved
0100H 01-00 0200H 02-00
0001H 00-01 0101H 01-01 0201H 02-01
0002H 00-02 0102H 01-02 0202H 02-02
0003H 00-03 0103H 01-03 0203H 02-03
0004H
Reserved
0104H 01-04 0204H 02-04
0005H 00-05 0105H 01-05 0205H 02-05
0006H
Reserved
0106H 01-06 0206H
Reserved
0007H 00-07 0107H
Reserved
0207H
Reserved
0008H 00-08 0108H
Reserved
0208H
Reserved
0009H 00-09 0109H 01-09 0209H
Reserved
000AH 00-10 010AH
Reserved
020AH
Reserved
000BH 00-11 010BH 01-11 020BH
Reserved
000CH 00-12 010CH 01-12 020CH 02-12
000DH 00-13 010DH 01-13 020DH 02-13
000EH 00-14
Register
No.
Function Register
No.
Function Register
No.
Function
Group03 Group04 Group05
0300H
Reserved
0400H
Reserved
0500H 05-00
0301H 03-01 0401H 04-01 0501H
Reserved
