Tecsun PL-990x User Manual

8
Display indicates “ ”:
MW tuning steps are set to 10 kHz.
MW frequency range is 520 ~ 1710 kHz (for North and South America).
LW frequency range is 100 ~ 519 kHz.
SW frequency range is 1711 ~ 29999 kHz.
Enabling/Disabling Longwave (LW)
With the device off, press and hold the [ 2 ] (LW ON/OFF) button, the display
shows “ ” (enabled) or “ ” (disabled). To select the LW frequency band,
power on the device and then quick press the [ MW/LW ] button twice.
Settings When Using Internal/External Antennas
When using the telescopic whip antenna, push the antenna selector switch
[ ANT. SWITCH ] to “INT.”. When an external antenna is connected to the
[ ANTENNA ] socket, set the selector switch to “EXT.”.
Caution! When using an outdoor antenna, waterproofing and lightning
protection measures must be taken.

Tecsun PL-990x Specifications

General

Frequency Range AM	520 - 1710 kHz
Frequency Range SW	1711 - 29999 kHz
Frequency Range LW	100 - 519 kHz
Display	LCD with backlight
SSB	Yes
Selectivity FM	>60dB
Frequency Range FM	64-108 MHz
Type	Portable Radio
Modes	AM, FM, LW, SW, SSB
Audio Output	Headphone and speaker
Antenna	External antenna jack, telescopic antenna
Tuning Steps AM	1 kHz / 9 kHz / 10 kHz
Tuning Steps SW	1 kHz / 5 kHz
Sensitivity FM	3 μV
Sensitivity AM	1 mV/m
Selectivity AM	>60dB
Additional Features	Alarm clock, Sleep timer
