Tecsun PL-990x User Manual

14
Storing Stations During Auto Scan
To avoid any unwanted stations that might be stored during Auto Tuning
Storage (ATS), store stations manually during “Auto Scan” (see also page 11).
1) Use the [ PAGE - ] or [ PAGE + ] button to select a memory page.
2) Quick press the [ VF/VM ] button.
3) Quick press the [ FM ], [ MW/LW ] or [ SW ] button to select the frequency
band.
4) Press and hold the [ VF/VM ] button. The device will start to scan the entire
frequency band for available stations.
5) When a station of your liking is found, quick press the memory [ M ] button
to store it; the device continues to scan for the next available station.
6) To stop the auto scan feature, quick press the [ VF/VM ] button or gently
rotate the [ TUNING ] knob.
Auto Sorting Memory
This feature can automatically organize all stations that have been stored into
the memory. Turn the device off, and then press and hold the [ ] button
until the memory page number on the display starts running. Duplicate stations
are deleted and the remaining stations are organized:
In memory page P0, stations within a frequency band are sorted in sequence
from low to high frequency.
In memory pages P1-24, stations are sorted in sequence of frequency
(from low to high), and in sequence of band: FM, SW, MW, LW.

Tecsun PL-990x Specifications

General

Frequency Range AM	520 - 1710 kHz
Frequency Range SW	1711 - 29999 kHz
Frequency Range LW	100 - 519 kHz
Display	LCD with backlight
SSB	Yes
Selectivity FM	>60dB
Frequency Range FM	64-108 MHz
Type	Portable Radio
Modes	AM, FM, LW, SW, SSB
Audio Output	Headphone and speaker
Antenna	External antenna jack, telescopic antenna
Tuning Steps AM	1 kHz / 9 kHz / 10 kHz
Tuning Steps SW	1 kHz / 5 kHz
Sensitivity FM	3 μV
Sensitivity AM	1 mV/m
Selectivity AM	>60dB
Additional Features	Alarm clock, Sleep timer
