Tecsun PL-990x User Manual

Using the Radio’s Antennas
FM / Shortwave (SW):
When listening to FM or shortwave radio, extend the antenna and adjust its
length and direction in order to get the optimum reception.
Medium Wave (MW) / Long Wave (LW):
This radio uses an internal ferrite bar antenna to receive medium wave and
long wave broadcasts, the quality of which can be enhanced by changing the
device's position and direction.
10

Tecsun PL-990x Specifications

General

Frequency Range AM	520 - 1710 kHz
Frequency Range SW	1711 - 29999 kHz
Frequency Range LW	100 - 519 kHz
Display	LCD with backlight
SSB	Yes
Selectivity FM	>60dB
Frequency Range FM	64-108 MHz
Type	Portable Radio
Modes	AM, FM, LW, SW, SSB
Audio Output	Headphone and speaker
Antenna	External antenna jack, telescopic antenna
Tuning Steps AM	1 kHz / 9 kHz / 10 kHz
Tuning Steps SW	1 kHz / 5 kHz
Sensitivity FM	3 μV
Sensitivity AM	1 mV/m
Selectivity AM	>60dB
Additional Features	Alarm clock, Sleep timer
