Tecsun PL-990x User Manual

Turning the device on/off: Quick press the [ POWER/SLEEP ] button.
Volume control: Rotate the [ VOLUME ] knob upwards or downwards to select
your desired volume level.
Note: Volume control on this device is disabled when feeding audio through the
[ LINE OUT ] socket.
(1) LISTENING TO RADIO
VF (View Frequency) and VM (View Memory)
VF: VF mode is used when searching for new radio signals. Quick press the
[ VF/VM ] button. When the frequency indicator flashes, the VF mode is
activated.
VM: VM mode is used for looking up stations that have been stored into
memory. Quick press the [ VF/VM ] button. When the station memory
indicator in the top right corner of the display flashes, the VM mode is
activated.
Note: When the memory contains no stored stations, it is not possible to
access VM (View Memory) mode.
USING THE DEVICE
VF mode
Flashing 2 times
VM mode
Flashing 3 times
9

Tecsun PL-990x Specifications

General

Frequency Range AM	520 - 1710 kHz
Frequency Range SW	1711 - 29999 kHz
Frequency Range LW	100 - 519 kHz
Display	LCD with backlight
SSB	Yes
Selectivity FM	>60dB
Frequency Range FM	64-108 MHz
Type	Portable Radio
Modes	AM, FM, LW, SW, SSB
Audio Output	Headphone and speaker
Antenna	External antenna jack, telescopic antenna
Tuning Steps AM	1 kHz / 9 kHz / 10 kHz
Tuning Steps SW	1 kHz / 5 kHz
Sensitivity FM	3 μV
Sensitivity AM	1 mV/m
Selectivity AM	>60dB
Additional Features	Alarm clock, Sleep timer
