Size: 1100mm(L) x 240mm (W) x 1214mm (H)
[412mm(H)without stand]
43 1/3"(L) x 9 1/2" (W) x 47 5/6"(H)
[16 1/4"(H) without stand]
Weight: 82kg (181 LB) without stand
Swing Over Bed: 400mm (16in.)
Distance Between Centers: 600mm (24in.);
extendable in 510mm (20in.) units with
add-on Bed sections.
Swing Outboard: 740mm (29in.) with headstock
at 90° using outrigger tool rest.
Headstock:
Spindle Thread: M33 x 3.5 RH
(1)
or
1-1/4 x 8 TPI RH
(2)
Headstock Bore: No. 2 Morse Taper (#2 MT)
Headstock Swivel: 0 to 360 degrees, with
detents at 0, 22.5, 45, and 90 degrees.
Outboard End Internal Thread: M20 x 1.5 LH
Spindle Index: 24 divisions (every 15 degrees) 15mm
through-hole through Headstock
Tailstock:
Tailstock Bore: No. 2 Morse Taper (#2 MT)
Quill Travel: 85mm (3-1/4in.)
Hole Through Tailstock: 15mm (9/16in.)
Tool rest:
Length: 300mm (12in.)
Shaft Diameter: 25.4mm (1in.)
Speeds (rpm):
100 – 3500 RPM is default (option in settings to
increase to 5000 RPM)
Favorite Speeds:
10 presets
Standard Equipment:
300mm (12in.) Tool rest,
80mm (3in.) Faceplate
Spur Center
Live Center
Outboard Handwheel.
Optional Accessories:
Precision Midi, G3, SuperNova 2, NOVA Infinity,
Titan Chuck
150mm (5.9in.) Faceplate
100mm (4in.) Tool rest
Bowl Tool rest
Outrigger Tool rest Unit
Revolving Center System
Faceplate rings
Bed Extension
Notes:
(1) Applicable to Europe
(2) Applicable to United States, Canada, Australia,
New Zealand & South Africa.
* Note: Standard equipment varies from country to
country, In some markets, the faceplate is an optional
accessory. Check with your reseller if you are unsure.
For Europe, Australasia, UK and South Africa
Directives this equipment complies with:
Low voltage directive (LVD) 73/23/EEC + 93/68/EEC +2006/95/EC
Machinery directive (MD) 89/392/EEC + 91/368 EEC + 93/68/EEC +
2006/42/EC Electromagnetic compatibility directive (EMCD)
89/336/EEC + 92/31/EEC + 93/68/EEC + 2004/108/EC
Harmonized Standards applied in order to verify compliance with
Directives:EN 61029-1:2009 (Low Voltage Directive and Machinery
Directive)
EN 55014-1:2007
EN 55014-2:2009
EN 61000-3-2: Ed3 2006
EN 61000-3-3:1995 A1 + A2
Signed Dated 07/23/2015
Spencer Herran
Research and Development Engineer
