Using the Nova DVR SATURN
Parts of the NOVA DVR SATURN Wood lathe
DVR Variable Speed Controller
The NOVA DVR drive is a unique type of drive system where the motor and controller interact with one another. The motor provides data
to the controller about its positon and load condition. Controller then processes the information sent from the motor to deliver power to the
motor for optimal performance and minimal losses.
DVR Drive Parameters
Motor Type
Digital Variable Reluctance
Motor Power
1.75HP for 115V
2.0HP for 230V
Accuracy of Speed Stabilization
<2.5%
Speed Stabilization
Current Level, Pulse Width
Motor Speed Range
100~5000 rpm
Default Speed (When powering up)
500 rpm
Reverse Function
Yes
Regulator Type
PID
Speed Control
Button (5 rpm increment)
