Tektronix 2213 Operator's Instruction Manual

2213 Operators
Table 2
(cont)
Characteristics
I
Performance Requirements
Supplemental Information
TRIGGER SYSTEM
(cont)
LEVEL Control Range (with
NORM TRIGGER MODE)
(cont)
At least 520 V (40 V p-~).~
EXT and DC+ 10
VAR HOLDOFF Control Range
Increases sweep
holdoff time by at least
a factor of
four.a
HORIZONTAL DEFLECTION SYSTEM
Sweep Rate
Calibrated Range
A Sweep
0.5 s per division to 0.05
pus per division
in a l-2-5 sequence. Xl 0 Magnifier
extends maximum sweep speed to 5 ns
per division.
Unmagnified
I
Magnified Sweep accuracy applies over the center
8 divisions. Exclude the first 50 ns of
the sweep for both magnified and un-
magnified sweep speeds and exclude
anything beyond the 100th magnified
division.
Accuracy
+2o”c to +3o”c
+3%
+5%
0” c to +5o”c
+6%a
POSITION Control Range
Start of sweep to 100th division will
position past the center vertical graticule
line with
X10 Magnifier.
Variable Control Range
Continuously variable between calibrated
settings. Extends the sweep speeds by at
least a factor of 2.5.
Delay Time
Range Selector
Minimum delay is less than selected values
of 0.5
ps, 10 ps, and 0.2 ms.
MULTIPLIER Control
Increases delay time by at least a factor
of 20.
Jitter
One part, or less, in 5,000 (0.02%) of the
maximum available delay time.
X-Y OPERATION (Xl MAGNIFICATION)
Deflection Factors
Range
Same as Vertical Deflection System, with
both
VOLTS/DIV Variable controls in
CAL detent.
aPerformance Requirement not checked in Service Manual.
@
29
