2213 Operators
Table 2
(cont)
Characteristics
I
Performance Requirements
Supplemental Information
X-Y OPERATION (Xl MAGNIFICATION)
(cont)
Deflection Factors
(cont)
Accuracy
+2o”c
to
+3o”c
0°C to
+5o”c
Bandwidth
X-Axis
X-Axis Y-Axis
Measured with a dc-coupled, 5-division
A
reference signal.
+5%
+3%
-+6%a
k4%a
Measured with a 5-division reference
signal.
D
C
to at least 2 MHz.
Y-Axis
Same as Vertical Deflection System.
Phase Difference Between X-
and Y-Axis
Amplifiers
+3’ from dc to 50
kHz.a
With dc-coupled inputs.
PROBE ADJUST
Signal at PROBE ADJUST Jack
Voltage
0.5 v
220%
.
Repetition Rate
1
kHz
?20%.a
Z-AXIS INPUT
Sensitivity
5 V causes noticeable modulation.
Positive-going input signal decreases
intensity.
Usable Frequency Range
D
C
to 5 MHz.~
I
Maximum Safe Input Voltage
30 V (dc + peak ac) or
30 V p-p ac at 1
kHz
or
less.a
Input Impedance
10
ka
+lO%
a
-
.
POWER SOURCE
Line Voltage Range
90 V to 250
V.a
Line Frequency Range
48 Hz to 62
Hz.~
Maximum Power Consumption 50
W.a
Line Fuse
2 A, 250 V, fast.
aPerformance Requirement not checked in Service Manual.
30
