TM 11-6625-2735-14-1
TABLE 1-1 (cont)
ELECTRICAL
Characteristics
Performance Requirements
Supplemental Information
LEVEL Control Range
EXT
EXT 10
Trigger View
Deflection
Factor
Risetime
Delay Difference
Centering of Trigger
Point
Calibrated Sweep Range
A Sweep or B DLY’D Sweep
A Delaying Sweep
(or A INTEN)
TRIGGER SYSTEM (cont)
At least + and –2 V, 4 V P-P.
At least + and –20 V, 40 V P-P.
Exclude LF REJ coupling mode.
Approximately 50 mV/DIV.
±20%. Exclude LF REJ and HF REJ
trigger coupling modes.
4.0 ns over the 10% to 90% part
of the fast-rise portion.
2.5 ns with a 5 division signal
having 1 ns or less risetime from a 25
source, centered vertically with
equal cable length from signal
source to vertical channel and ex-
ternal trigger inputs, each termin-
ated in 50
Adjustable to within 1.0 division
of center screen.
Horizontal DEFLECTION SYSTEM
0.5 s/DIV to 0.01 /DIV in 24 steps;
1-2-5 sequence. X10 MAG extends max-
imum sweep rate to 1 ns/DIV.
0.5 s/DIV to 0.05 DIV in 22 steps:
1-2-5 sequence.
1-5
