Tektronix AFG3000 Series User Manual

Specifications
AFG3000 Series Quick Start User Manual
67
Output Characteristics
Sine Wave AFG3021/AFG3022 AFG3101/AFG3102 AFG3251/AFG3252
✔Flatness
(at 1.0 V
p-p
amplitude (+4 dBm),
relative to 100 kHz)
<5 MHz: ±0.15 dB
≥5 MHz to 20 MHz:
±0.3 dB
≥20 MHz to 25 MHz:
±0.5 dB
<5 MHz: ±0.15 dB
≥5 MHz to 25 MHz:
±0.3 dB
≥25 MHz to 100 MHz:
±0.5 dB
<5 MHz: ±0.15 dB
≥5 MHz to 25 MHz:
±0.3 dB
≥25 MHz to 100 MHz:
±0.5 dB
≥100 MHz to 200 MHz:
±1.0 dB
≥200 MHz to 240 MHz:
±2.0 dB
✔Harmonic Distortion
(at 1.0 V
p-p
amplitude)
10 Hz to 20 kHz: <–70 dBc
≥20 kHz to 1 MHz:
<–60 dBc
≥1 MHz to 10 MHz:
<–50 dBc
≥10 MHz to 25 MHz:
<–40 dBc
10 Hz to 1 MHz: <–60 dBc
≥1 MHz to 5 MHz:
<–50 dBc
≥5 MHz to 100 MHz:
<–37 dBc
10 Hz to 1 MHz: <–60 dBc
≥1 MHz to 5 MHz:
<–50 dBc
≥5 MHz to 25 MHz:
<–37 dBc
≥25 MHz to 240 MHz:
<–30 dBc
✔Total Harmonic Distortion
(at 1 V
p-p
amplitude)
10 Hz to 20 kHz: <0.2%
✔Spurious
1
(nonharmonic)
(at 1 V
p-p
amplitude)
10 Hz to 1 MHz: <–60 dBc
≥1 MHz to 25 MHz:
<–50 dBc
10 Hz to 1 MHz: <–60 dBc
≥1 MHz to 25 MHz:
<–50 dBc
≥25 MHz to 100 MHz:
–50dBc + 6dBc/oct
10 Hz to 1 MHz: <–50 dBc
≥1 MHz to 25 MHz:
<–47 dBc
≥25 MHz to 240 MHz:
–47dBc + 6dBc/oct
Phase Noise, typical
(at 1 V
p-p
amplitude)
20 MHz: <–110 dBc/Hz at 10 kHz offset
Residual Clock Noise,
typical
–63dBm –57dBm –57dBm
Square Wave AFG3021/AFG3022 AFG3101/AFG3102 AFG3251/AFG3252
✔Rise Time/Fall Time ≤ 18 ns ≤ 5ns ≤ 2.5 ns
Jitter (rms), typical 500 ps 200 ps 100 ps
Pulse AFG3021/AFG3022 AFG3101/AFG3102 AFG3251/AFG3252
Pulse Width 30 ns to 999.99 s 8 ns to 999.99 s 4 ns to 999.99 s
Resolution 10 ps or 5 digits
Pulse Duty 0.001% to 99.999%
Leading Edge/Trailing Edge 18 ns to 0.625 * Pulse
Period
5 ns to 0.625 * Pulse
Period
2.5 ns to 0.625 * Pulse
Period
Resolution 10 ps or 4 digits
Overshoot, typical <5%
Jitter (rms), typical 500 ps 200 ps 100 ps
