Tektronix AFG3000 Series User Manual

Specifications
68 AFG3000 Series Quick Start User Manual
Ramp AFG3021/AFG3022 AFG3101/AFG3102 AFG3251/AFG3252
Linearity
2
, typical ≤ 0.1% of peak output ≤ 0.15% of peak output ≤ 0.2% of peak output
Symmetry 0% to 100.0%
Noise AFG3021/AFG3022 AFG3101/AFG3102 AFG3251/AFG3252
Bandwidth, typical 25 MHz 100 MHz 240 MHz
Arbitrary AFG3021/AFG3022 AFG3101/AFG3102 AFG3251/AFG3252
Rise Time/Fall Time, typical ≤ 20 ns ≤ 8ns ≤ 3ns
Jitter (rms), typical 4 ns 1 ns at 1 GS/s
4 ns at 250 MS/s
500 ps at 2 GS/s
4 ns at 250 MS/s
1. Exclude harmonics and channel crosstalk.
2. Frequency: 1 kHz, Amplitude: 1 V
p-p
, Symmetry: 100%
10% to 90% of amplitude range
Modulation
AM (Amplitude Modulation)
Carrier Waveforms Standard waveforms (except Pulse, DC, and Noise) and Arb
Modulation Source Internal or External
Internal Modulating
Waveforms
Sine, Square, Ramp, Noise, and Arb
1
Internal Modulating
Frequency
2 mHz to 50.00 kHz
Depth 0.0% to 120.0%
FM (Frequency Modulation) AFG3021/AFG3022 AFG3101/AFG3102 AFG3251/AFG3252
Carrier Waveforms Standard waveforms (except Pulse, DC, and Noise) and Arb
Modulation Source Internal or External
Internal Modulating
Waveforms
Sine, Square, Ramp, Noise, and Arb
2
Internal Modulating
Frequency
2 mHz to 50.00 kHz
Peak Deviation DC to 12.5 MHz DC to 50 MHz DC to 120 MHz
PM (Phase Modulation)
Carrier Waveforms Standard waveforms (except Pulse, DC, and Noise) and Arb
Modulation Source Internal or External
Internal Modulating
Waveforms
Sine, Square, Ramp, Noise, and Arb
2
Internal Modulating
Frequency
2 mHz to 50.00 kHz
Phase Deviation Range 0.0 to 180.0 degrees
Output Characteristics (cont.)
