Tektronix Keithley 2260B Series User Manual

APPENDIX
177
2260B Specifications
The specifications apply when the 2260B is powered on for at least
30 minutes.
2260B 360W
2260B-30-36, 2260B-80-13, 2260B-250-4, 2260B-800-1
Model
Unit
2260B-
30-36
2260B-
80-13
2260B-
250-4
2260B-
800-1
Rated Output Voltage
V
30
80
250
800
Rated Output Current
A
36
13.5
4.5
1.44
Rated Output Power
W
360
360
360
360
Power Ratio
--
3
3
3.125
3.2
Constant Voltage Mode
Line Regulation (*1)
mV
18
43
128
403
Load Regulation (*2)
mV
20
45
130
405
Ripple and Noise (*3)
p-p (*4)
mV
60
60
80
150
r.m.s (*5)
mV
7
7
15
30
Temperature coefficient
ppm
/ºC
100ppm/°C of rated output voltage, after a
30 minute warm-up.
Remote sense compensation
voltage (single wire)
V
0.6
0.6
1
1
Rise Time (*6)
Rated Load
ms
50
50
100
150
No Load
ms
50
50
100
150
Fall Time (*7)
Rated Load
ms
50
50
150
300
No Load
ms
500
500
1200
2000
Transient response time (*8)
ms
1
1
2
2
Constant Current Mode
Line regulation (*1)
mA
41
18.5
9.5
6.44
Load regulation (*9)
mA
41
18.5
9.5
6.44
Ripple and noise
r.m.s (*5)
mA
72
27
10
5
Temperature coefficient
ppm
/ºC
200ppm/°C of rated output current, after a
30 minute warm-up.
