Tektronix Keithley 2260B Series User Manual

OPERATION
49
Output Terminals 2260B-250/800
Background
The high voltage models (2260B-250 and 2260B
-800 models) use a 9 pin socket for the output
voltage and sense connections. The
corresponding plugs should be used to connect
the terminals to the appropriate cable.
Before connecting the output terminals to the
load, first consider whether voltage sense will
be used, the gauge of the cable wiring and the
withstand voltage of the cables and load.
WARNING
Dangerous voltages. Ensure that the power to the
instrument is disabled before handling the power
supply output terminals. Failing to do so may lead
to electric shock.
Please note the wire gauge used and the capacity
of the plug/socket. It may be necessary to wire the
load to a number of terminals to offset the
capacity over a number of terminals.
Output Connector
Overview
When using the output connector make sure
the wires that are used follow the following
guidelines:
Wire gauge:
AWG 26 to AWG 16
Strip length
6.5mm // 0.26 in.
Current rating
10A
Insulation resistance
AC 2000V min
Insulation withstand
voltage
>2000MΩ DC500V
Operation
Temperature
-40ºC to +105ºC
