Tektronix Keithley 2260B Series - Using the Output Terminal Cover 2260 B-250;800

OPERATION
53
Using the Output Terminal Cover 2260B-250/800
Steps
1. Screw the bottom
cover onto the rear
panel using the two
M4 screws.
1
2. Slide the top cover
over the bottom
cover.
2
3. Finally, secure the
top cover with the
screw in the center of
the top cover.
3
Removal
Reverse the procedure to remove the terminal
covers.
