Tektronix Keithley 2260B Series User Manual

2260B Series User Manual
180
Front Panel
Display, 4 digits
Voltage accuracy at
23˚C±5˚C; ±(0.1% +)
mV
20
20
200
400
Current accuracy at
23˚C±5˚C; ±(0.1% +)
mA
40
20
5
2
Indications
GREEN LED's: CV, CC, VSR, ISR, DLY, RMT,
20, 40, 60, 80, 100, %W, W, V, A
RED LED's: ALM
Buttons
Function, OVP/OCP, Set, Test, Lock/Local,
PWR DSPL, Output
Knobs
Voltage, Current
USB port
Type A USB connector
Programming and Measurement (USB, LAN, GPIB)
Output voltage programm-
ing accuracy at 23˚C±5˚C;
±(0.1% +)
mV
10
10
200
400
Output current programm-
ing accuracy at 23˚C±5˚C;
±(0.1% +)
mA
30
10
5
2
Output voltage
programming resolution
mV
1
2
5
14
Output current
programming resolution
mA
1
1
1
1
Output voltage measure-
ment accuracy at 23˚C±5˚C;
±(0.1% +)
mV
10
10
200
400
Output current measure-
ment accuracy at 23˚C±5˚C;
±(0.1% +)
mA
30
10
5
2
Output voltage
measurement resolution
mV
1
2
5
14
Output current
measurement resolution
mA
1
1
1
1
Series and Parallel Capability
Parallel number
Units
3
3
3
3
Series Number
Units
2
2
None
None
Input Characteristics
Nominal input rating
100Vac to 240Vac, 50Hz to 60Hz, single
phase
Input voltage range
85Vac ~ 265Vac
Input voltage range
47Hz ~ 63Hz
Maximum input current
100Vac
A
5

Tektronix Keithley 2260B Series Specifications

General

Brand	Tektronix
Model	Keithley 2260B Series
Category	Power Supply
Language	English
