Tektronix Keithley 2260B Series User Manual

APPENDIX
187
Interface Capabilities
USB
TypeA: Host, TypeB: Slave, Speed: 1.1/2.0,
USB Class: CDC(Communications Device
Class)
LAN
MAC Address, DNS IP Address, User
Password, Gateway IP Address, Instrument
IP Address, Subnet Mask
GPIB
Optional: GUG-001 (GPIB to USB Adapter)
Environmental Conditions
Operating temperature
0˚C to 50˚C
Storage temperature
-25˚C to 70˚C
Operating humidity
20% to 85% RH; No condensation
Storage humidity
90% RH or less; No condensation
Altitude
Maximum 2000m
General Specifications
Weight (main unit only)
kg
Approx. 5.3kg
Dimensions (WxHxD)
mm
3
142×124×350
Cooling
Forced air cooling by internal fan.
EMC
Complies with the European EMC directive
2004/108/EC for Class A test and
measurement products.
Safety
Complies with the European Low Voltage
Directive 2006/95/EC and carries the CE-
marking.
Withstand voltage
Between input and chassis: No
abnormalities at 1500 Vac for 1 minute.
Between input and output: No
abnormalities at 3000 Vac for 1 minute.
Between output and chassis: No
abnormalities at 500 Vdc for 1 minute for
30V and 80V models.
No abnormalities at 1500 Vdc for 1 minute
for 250V, 800V models.
Insulation resistance
Between input and chassis: 500 Vdc,
100MΩ or more
Between input and output: 500 Vdc, 100MΩ
or more
Between output and chassis: 500 Vdc,
100MΩ or more for 30V, 80V and 250V
models.
1000Vdc, 100MΩ or more for 800V models.
*1: At 85 ~ 132Vac or 170 ~ 265Vac, constant load.
*2: From No-load to Full-load, constant input voltage. Measured at the sensing
point in Remote Sense.
