Tektronix Keithley 2260B Series User Manual

APPENDIX
191
CV/CC/ALM/PWR
ON/OUT ON indicator
Photocoupler open collector output;
Maximum voltage 30V, maximum sink
current 8mA.
Front Panel
Display, 4 digits
Voltage accuracy at
23˚C±5˚C; ±(0.1% +)
mV
20
20
200
400
Current accuracy at
23˚C±5˚C; ±(0.1% +)
mA
100
50
20
6
Indications
GREEN LED's: CV, CC, VSR, ISR, DLY, RMT,
20, 40, 60, 80, 100, %W, W, V, A
RED LED's: ALM
Buttons
Function, OVP/OCP, Set, Test, Lock/Local,
PWR DSPL, Output
Knobs
Voltage, Current
USB port
Type A USB connector
Programming and Measurement (USB, LAN, GPIB)
Output voltage programm-
ing accuracy at 23˚C±5˚C;
±(0.1% +)
mV
10
10
200
400
Output current programm-
ing accuracy at 23˚C±5˚C;
±(0.1% +)
mA
100
40
15
6
Output voltage
programming resolution
mV
1
2
5
14
Output current
programming resolution
mA
3
3
1
1
Output voltage measure-
ment accuracy at 23˚C±5˚C;
±(0.1% +)
mV
10
10
200
400
Output current measure-
ment accuracy at 23˚C±5˚C;
±(0.1% +)
mA
100
40
15
6
Output voltage
measurement resolution
mV
1
2
5
14
Output current
measurement resolution
mA
3
3
1
1
Series and Parallel Capability
Parallel number
Units
3
3
3
3
Series Number
Units
2
2
None
None
