2260B Series User Manual
80
Master with 1 slave unit:
2
12
131517
20
21
24 20 12
17 15 3
23
OUTPUT ON STATUS21
Master unit
ALM STATUS20
STATUS COM17
FEEDBACK15
CURRENT_SUM_113
SHUTDOWN12
OUT ON/OFF CONT24
Slave Unit 1
12 SHUTDOWN
20 ALM STATUS
15 FEEDBACK
3 CURRENT SUM OUT
17 STAT US COM
2 D COM
11 1I MON CURRENT SHARE
11 1
16 16A COM A COM
16
16
Parallel Output
Connection
-
+
Load
Master
unit
Slave
unit 2
Slave
unit 1
Steps
1. Ensure the power is off on all power supplies.
2. Choose a master and a slave unit(s).
3. Connect the analog connectors for the master
and slave unit as shown above.
4. Remove the Output Terminal
covers and the protection dummy
plug from the analog control
connector.
Page 47
