Model 2601B-PULSE System SourceMeter® Instrument User's Manual Section 3: Instrument description
2601B-PULSE-900-01 Rev. A August 2021 3-9
The following table contains descriptions of the main menu options and cross-references to related
information.
To access a menu option, press the MENU key, turn the navigation wheel to move the cursor to
select an item, and press the navigation wheel.
Menu selection
Description
For more information, see:
SCRIPT
Saves and recalls user scripts
Model 2601B-PULSE Reference Manual,
“Manage scripts”
- LOAD
Loads scripts into nonvolatile memory
- SAVE
Saves scripts
SETUP
Saves and recalls user and factory setup options
Model 2601B-PULSE Reference Manual,
“Saved setups”
- SAVE
Saves user setup options
- RECALL
Recalls user setup options
- POWERON
Sets the configuration used during startup
GPIB
Configures the GPIB interface options
Remote communications interfaces (on
page 2-12)
- ADDRESS
Configures the address for the GPIB interface
- ENABLE
Enables and disables the GPIB interface
LAN
Configures the local area network (LAN)
LAN communications (on page 2-15)
- STATUS
Displays LAN connection status
- CONFIG
Configures the LAN IP address and gateway
- APPLY_SETTINGS
Applies changes made using the CONFIG menu
- RESET
Restores the default settings
- ENABLE
Enables and disables the LAN interface
RS232
Controls the options for the RS-232 interface
Remote communications interfaces (on
page 2-12)
- BAUD
Sets the baud rate
- BITS
Configures the number of bits
- PARITY
Sets the parity
- FLOW-CTRL
Configures the flow control
- ENABLE
Enables and disables the RS-232 interface
TSPLINK
Configure the instrument in a TSP-Link
®
network
Model 2601B-PULSE Reference Manual,
“TSP-Link system expansion interface”
- NODE
Selects the instrument node identifier
- RESET
Resets the TSP-Link network
UPGRADE
Upgrades the firmware from a USB flash drive
Upgrading the firmware (on page 5-4)
DISPLAY
Accesses display functions
Front-panel tests (on page 5-3)
- TEST
Runs the display test
See Numeric entry method in Setting a
value (on page 3-12)
- NUMPAD
Enables and disables the numeric keypad
DIGOUT
Controls digital outputs
Model 2601B-PULSE Reference Manual,
“Digital I/O”
- DIG-IO-OUTPUT
Selects the digital I/O values
- WRITE-PROTECT
Write-protects specific digital I/O lines
- LEGACY-MODE
Sets digital I/O to work like an older
SourceMeter instrument
